Introduction

I offer various models of classical concert guitars, both modern and historic. Some are copies of specific historic instruments, others are more loosely based on historic instruments and others are my own models, developed over the course of my career but still having a strong basis in the tradition of Spanish guitars. Most of my instruments can be selected with a choice of woods and decorative appointments, string scales and spacing as well as neck profiles. Some instruments are usually available right away from my shop, either newly constructed or exhibition guitars remaining from previous years' production. All models can be ordered by commissions, during which I engage in a thorough process of dialogue to provide an instrument exactly tailored to the individual's preferences of tonality and playability. Please contact me for lead times and prices.

The following section provides a list of instruments currently available, followed by a final section giving a description and history of the modern and historic models I offer.


Instruments currently for sale

2024 Batell Cedar, Granada model #128
2024 Batell Spruce Double-top, Granada model #129
2024 Batell Cedar double-top, Granada model #127
2022 Batell Cedar, Granada model #118
2022 Batell Spruce, Santos Hernandez model #117

Available:

2024 Batell Cedar, Granada model #128

  • Soundboard: Cedar
  • Back & Sides: Makassar Ebony
  • Neck: Spanish Cedar
  • Fingerboard: Gabon Ebony
  • Tuners: Barnett brass engraved w/ Snakewood
  • Weight: 1615 grams
  • Neck width at nut, at 12th fret: 52.5, 62
  • String lenght, spacing at nut-bridge: 650, 42.5, 59.5
Inquire for price

This instrument, constructed in the Spanish tradition, is based on my own "Granada" model, approximately comparable to the Santos Hernandez in size but deeper. It has a very low fundamental frequency response which gives it very profound basses as well as reinforced trebles and harmonic respononse. It has exceptional power, clarity, and ease of playing.

This guitar will be exhibited at the Paganini Guitar Festivel and Expo in Parma, 22-24 November, 2024 - see exhibition page for details.

The guitar may also be heard on the following video:

Video: Ivan Petricevic performing "Prelude in E-major" by Manuel María Ponce Video: Valeria Galimova performing Koyunbaba by Carlo Domeniconi


click photos to zoom in


Gallery/workshop visits are welcome, please call or email for appointment.



Available:

2024 Batell Spruce Double-top, Granada model #129

  • Soundboard: Spruce
  • Back & Sides: Makassar Ebony
  • Neck: Mahogany
  • Fingerboard: Gabon Ebony
  • Tuners: Barnett brass w/ Snakewood
  • Weight: 1615 grams
  • Neck width at nut, at 12th fret: 52.5, 62
  • String lenght, spacing at nut-bridge: 650, 42.5-59
Inquire for price

This instrument is constructed in the Spanish tradition, but with double-top soundboard technology. Its response is effortless, with exceptional power, clarity, and ease of playing.

This guitar will be exhibited at the Aalborg Guitar Festival & Competitions, 22-24 November, 2024 - see exhibition page for details. The instrument is for sale at any time, before or after the festival.

The guitar may also be heard on the following video:

Video: Kanahi Yamashita performs "Rondó-Scherzo" from Sonata V by Carlo Domeniconi

Video: Kanahi Yamashita performs "Oración por Todos" by Agustin Barrios Mangoré


click photos to zoom in


Gallery/workshop visits are welcome, please call or email for appointment.



Available

2024 Batell Cedar double-top, Granada model #127

  • Soundboard: Cedar/Nomex
  • Back & Sides: Makassar Ebony
  • Neck: Mahogany
  • Fingerboard: Gabon Ebony
  • Tuners: Barnett Brass plates, Snakewood buttons
  • Weight: 1615 grams
  • Neck width at nut, at 12th fret: 52.5, 62
  • String lenght, spacing at nut-bridge: 650, 42.5-59

This instrument is constructed in the Spanish tradition and possesses every aspect of color palette, sustain, balance and harmonic response one expects from the best traditional guitars, but it is augmented by the additional power, projection and speed one expects from double-top construction. Its response is effortless and immediate throughout its wide dynamic range.

This guitar may be heard in the following video:

Video: Samuel Beluzán Rodríguez performing "Lamentos do Morro" by Garoto*


click photos to zoom in


Gallery/workshop visits are welcome, please call or email for appointment.



Available:

2022 Batell Cedar, Granada model #118

  • Soundboard: Cedar
  • Back & Sides: Makassar Ebony
  • Neck: Spanish Cedar
  • Fingerboard: Gabon Ebony
  • Tuners: Barnett brass engraved w/ Snakewood
  • Weight: 1515 grams
  • Neck width at nut, at 12th fret: 52.5, 62
  • String lenght, spacing at nut-bridge: 640, 42.5-57
Inquire for price

This instrument, constructed in the Spanish tradition, is a slightly smaller version of my own "Granada" model, approximately comparable to the Manuel Ramirez in size. Its response is effortless, with exceptional power, clarity, and ease of playing.

This guitar will be exhibited at 26. Aalborg Guitar Festival & Competitions, 11-19 November, 2023 - see exhibition page for details.

The guitar may also be heard on the following video:

Video: Takuya Okamoto: Passacaglia from Sandy's Portrait by Sergio Assad


click photos to zoom in


Gallery/workshop visits are welcome, please call or email for appointment.



Available:

2022 Batell Spruce, Santos Hernandez model #117

  • Soundboard: Spruce
  • Back & Sides: Indian Rosewood
  • Neck: Spanish Cedar
  • Fingerboard: Gabon Ebony
  • Tuners: Barnett brass w/ Ebony
  • Weight: 1450 grams
  • Neck width at nut, at 12th fret: 52.5, 62
  • String lenght, spacing at nut-bridge: 650, 42.5-59
Inquire for price

This instrument, constructed in the Spanish tradition, after a Santos Hernandez of 1931. The rosette is also after a typical Santos Hernandez style. Its response is explosive, with exceptional power, clarity, and ease of playing.

This guitar will be exhibited at 26. Aalborg Guitar Festival & Competitions, 11-19 November, 2023 - see exhibition page for details.

The guitar may also be heard on the following video:

Video: Julia Villarroel performs "Saudade No. 3" by Roland Dyens


click photos to zoom in


Gallery/workshop visits are welcome, please call or email for appointment.


Description of Models

Granada Model (since 2017)

My use of the title Granada requires an explanantion and a grain of salt. This model is in no direct way influenced by what is sometimes called the Granada school of guitar making, for there is actually no such thing in any organized way. The makers of Granada come from diverse backgrounds and all follow their own design principles, not necessarily similar to each other's. What one can say in general is that since the mid 80's, the best instruments of Granada (significantly influenced by those of Antonio Marin after his association with Robert Bouchet) reflect a break from the larger mid to late 20th C. Madrid instruments, evidencing rather a re-examination of the origins of the modern guitar and the principlies established by Torres and others.

Having been originally influenced by Spanish guitars of the 60's and 70's, I later experienced the same kind of evolution and renewed understanding of older traditional guitars. When I returned to building again in Berlin (my own second epoch beginning 2009), I began to base my designs more closely on the principles of Torres and the generation of makers who followed him into the early 20th C. In this way, I think it is appropriate to use name "Granada" to indicate the direction I took in arriving at this model. The Granada model uses my own plantilla, developed over a long career and revealing a mixture of elemental shapes of Torres, Hernandez and others. I have also returned to a simpler architecture and internal bracing reflective of Torres. The result is a lightly made guitar of exceptional clarity, definition, response, power and sustain with a rich and complex pallet of color and overtones.

click photos to zoom in

An example of this model in Spruce may be heard on the following video: Video: Goran Krivokapić performs Vals Venezolano No. 3 by Antonio Lauro

Santos Hernandez Model (since 2019)

The Hernandez model was developed in the beginning of 2019. The plantilla and other elements of the construction are based on a 1931 Santos Hernandez which belonged to the Romero family - possibly originally to Celedonio but eventually to Pepe Sr., who reputedly played this instrument for Pepe Jr. when he was in the womb and after his birth, thus "playing" him into this world. The Hernandez, like the Granada model, offers exceptional power, definition, sustain, and brilliance combined with a very Spanish flavor, and with an explosive quality in attack. My flamenco guitars are also based on the instruments of Santos Hernandez, who was well known additionally for his excellent flamenco guitars.

click photos to zoom in

An example of this model with Cedar double-top may be heard on the following video: Video: Julia Trintschuk plays "Berliner Tango" by Sebastian Pecznik

Manuel Ramirez Model (since 2021)

The Ramirez model was developed in late 2021 as a project I undertook to reproduce 2 additional historic guitars (besides the Hernandez model) which are an important part of the heritage from which my building derives. This model is a very faithful reproduction of the Manuel Ramirez classical of 1912 (ascribed in large part to Santos Hernandez when he worked in the shop of Manuel), which was presented to the young Segovia and was later the basis for the guitar made for him by Hermann Hauser I. My Ramirez model follows the architecture, internal bracing, weight (and resulting wood thicknesses), as well as the general decorative and aesthetic aspects of the original, thus offering a close rendition of what the original might have looked, played and sounded like when it was new. Like the later Hernandez guitars made under his own label, this Ramirez model is bright and incisive, with excellent balance, clarity and an explosive attack.

click photos to zoom in

An example of the instrument shown may be heard on the following video: Video: Nelly von Alven: "Nocturne" by Rossen Balkanski

Antonio de Torres Model (since 2021)

The Torres model was developed in late 2021 as part of the project I undertook to reproduce 2 additional historic guitars (besides the Hernandez model) which are an important part of the heritage from which my building derives. This model is a very faithful reproduction of the 1860 Antonio de Torres guitar, reference number FE13, which was one of the Torres guitars owned by Miguel Llobet and which later came into the hands of Hermann Hauser I, subsequently becoming the basis for many of Hauser's own models. My version precisely follows the architecture, internal bracing, weight (and resulting wood thicknesses), as well as the decorative and aesthetic aspects of the original Torres, thus offering a close rendition of what the original might have looked, played and sounded like when it was new. The instrument possesses a lush and clear sound, with excellent balance, power and sustain, and a tonality distinctly evoking an older era.

click photos to zoom in

An example of the instrument shown may be heard on the following video: Video: Luiz Mantovani, performing Anton Diabelli - Sonata in F, Op.29, No. 3 - 2. Andante sostenuto

Classical Crossover Model (since 2020)

The Classical Crossover model is designed for the stage artist who needs to play plugged and with modern jazz ensembles. It has a cut-away side enabling easier fingering in upper positions for finger-style and new music. This instrument is typically also provided with a high-end blend pick-up system (piezzo and mic) and on-board preamp. These instruments are nonetheless still constructed in traditional Spanish method, with volume, response, balance and clarity ideal for unamplified concert performance. They are still based on one of my historic or modern models (Ramirez, Hernandez, or "Granada"), and can be constructed according to the artist's preferences of tonality and playability.

click photos to zoom in

An example of the instrument shown may be heard on the following video: Video: Fabian Zeller, performing "Marceneiro Paulo" by Helio Delmiro
